Nobels MOD-mini Compact Stereo Modulation effect pedal
Nobels MOD-mini
The new Nobels MOD-mini combines an outstanding selection of legendary modulation effects in a deceivingly compact housing. Featuring intuitive switching and versatile option for seamless performance, the MOD-mini keeps the regular Nobels extras with its fold-out Mounty-P mounting plates and ‘Glow in the Dark’ pointer knobs. And all this at an extremely attractive price!
Get ready to dial up the vibe with the MOD-mini, a compact powerhouse packed with lush modulation effects! Crafted to create epic sounds, this diminutive pedal delivers a kaleidoscope of tones with a wide stereo spread. From the pulsating tremolo of the swinging‚ 60s to the funky phaser and U-Vibe grooves of the ‚70s, MOD-mini takes you into a sonic time warp.
Tap Tempo Magic: Crank up the creativity with extended speed ranges and watch the LED dance to your rhythm.
Your Sound, Your Way: Flip between true or buffered by-pass with a slick toggle switch for ultimate flexibility.
Big Vibes, Small Price: Classic modulation tones meet wallet-friendly affordability.
The MOD-mini isn’t just a pedal—it’s your ticket to a retro-inspired sonic adventure!
German Engineering. Made in China.
FEATURES
- 3 Modulation Models (Tremolo - Phaser - U-Vibe)
- Tap Tempo - with extended speed range
- Selectable Mono or Stereo (TRS) inputs and outputs
- Selectable True- or Buffered Bypass
- “Glow in the Dark” knob indicators
- Mounty-P mounting plates
- Small compact metal enclosure
- Light weight
SPECS
- Power: stabilized and filtered power supply 9 Volts DC (not included)
- DC plug: 2.1 mm / negative center
- Consumption: less than 100mA
- Input impedance: 1M ohm
- Output impedance: 10K Ohm
- Dynamic range: 106 dB (w/o effect through DSP Buffer)
- DSP Processing: 48 kHz / 32 bit - A/D D/A Sampling Rate 48 kHz / 24 bit
- Controls: Rate, Width, Mix
- Switches: Mode, Bypass, Mono-Stereo, On/Off (Tap Tempo)
- Jacks: DC, Input TRS 1/4“ (6.3 mm), Output TRS 1/4“ (6.3 mm)
- Indicator (LED): 1x Multicolor LED: (On/Off, Mode and Tap Tempo)
- Tremolo: green LED
- Phaser: red LED
- U-Vibe: blue LED
- Mounty-P: 4x fold-out mounting plates
- Dimensions (cm): LxWxH 9.37 x 4.85 x 5.13; 12 x 6.95 x 6.5 (boxed)
- Weight (gr): 210 / 301 (boxed)
- (Specifications are subject to change without notice)
